Ford Escape: Parking Aid - Vehicles With: Rear Parking Aid / Removal and Installation - Parking Assist Control Module (PAM)

Removal

All vehicles

  1. NOTE: If installing a new PAM , it is necessary to upload the module configuration information to the scan tool prior to removing the module. This information must be downloaded into the new PAM after installation.

    Using a diagnostic scan tool, begin the PMI process for the PAM following the onscreen instructions.
  1. Remove the floor console.
    Refer to: Floor Console (501-12 Instrument Panel and Console, Removal and Installation).

Advanced Automated Parking System

  1. Disconnect the electrical connectors.
  1. Remove the fasteners and the PAM .

Less Automated Parking System

    • Disconnect the electrical connectors.
    • Release the harness retainer and position the harness aside.
  1. Position the floor carpet aside.
  1. Remove the nuts and the PAM assembly.
    Torque: 22 lb.in (2.5 Nm)
  1. NOTE: This step is only necessary when installing a new component.

    Remove the screws and the PAM from the bracket.

Installation

  1. To install, reverse the removal procedure.
  1. NOTE: This step is only necessary when installing a new component.

    Using a diagnostic scan tool, complete the PMI process for the PAM following the on-screen instructions.
