Ford Escape 2020-2025 Service Manual / Body and Paint / Body and Paint / Supplemental Restraint System / Removal and Installation - Seat Position Sensor

Ford Escape: Supplemental Restraint System / Removal and Installation - Seat Position Sensor

Removal

NOTE: RH (right-hand) seat shown, LH (left-hand) seat similar.

NOTE: Removal steps in this procedure may contain installation details.

1. Disconnect the seat position sensor electrical connector.
1. Remove the seat position sensor screw.
  Torque: 8 lb.in (0.9 Nm)
1. Remove the seat position sensor.

Installation

To install, reverse the removal procedure.
