Ford Escape: Parking Brake and Actuation / Removal and Installation - Parking Brake Switch
Special Tool(s) /
General Equipment
Removal
NOTE:
Removal steps in this procedure may contain installation details.
-
Release the clips and position aside the floor console upper trim panel.
-
Lift the front of the upper trim panel to release the clips.
-
Slide the upper trim panel forward to release the rear retaining tabs.
Use the General Equipment: Interior Trim Remover
-
Disconnect the parking brake switch electrical connector.
-
Remove the screws and the parking brake switch.
Torque:
9 lb.in (1 Nm)
Installation
-
To install, reverse the removal procedure.
-
NOTE:
Anytime the parking brake switch electrical connector has been
disconnected, the EPB system is deactivated and a DTC is stored in the
ABS module. Perform the following step to restore the EPB system and
clear the ABS module DTC .
Apply and release the parking brake twice within 5
seconds, pausing with the switch in the NEUTRAL position for
approximately one-half second between each apply and release.
