Ford Escape: Exterior Lighting / Removal and Installation - Front Turn Signal Lamp Bulb
Removal
NOTE:
Removal steps in this procedure may contain installation details.
-
Remove the front turn signal lamp bulb cover.
-
Rotate the front turn signal lamp bulb holder
counterclockwise and remove the turn signal bulb holder from the
headlamp assembly.
-
Remove the front turn signal lamp bulb.
Installation
-
To install, reverse the removal procedure.
Removal
Remove the front bumper cover.
Refer to: Front Bumper Cover (501-19 Bumpers, Removal and Installation).
Remove the front fog lamp...
Removal
NOTE:
Removal steps in this procedure may contain installation details.
Remove the center registers.
Refer to: Center Registers (412-00 Climate Control System - General Information, Removal and Installation)...
Other information:
Diagnostic Trouble Code (DTC) Chart
Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices. REFER to: Diagnostic Methods (100-00 General Information, Description and Operation).
Module
DTC
Description
Action
PCM
P059F:00
Active Grille Air Shutter 'A' Performance/Stuck Off: No Sub Type Information
GO to Pinpoint Test A
PCM..
Special Tool(s) /
General Equipment
Resistance Spotwelding Equipment
Scraper for Straight Edges
Hot Air Gun
Spot Weld Drill Bit
Locking Pliers
Materials
Name
Specification
Metal Bonding AdhesiveTA-1, TA-1-B, 3M™ 08115, LORD Fusor® 108B, Henkel Teroson EP 5055
-
Seam SealerTA-2-B, 3M™ 08308, LORD Fusor® 803DTM
-
Removal
 ..
