Ford Escape: Exterior Lighting / Removal and Installation - Front Fog Lamp

Removal

Remove the front bumper cover.
Refer to: Front Bumper Cover (501-19 Bumpers, Removal and Installation).

Remove the front fog lamp.
1. Detach the front fog lamp wire harness retainer.
1. Disconnect the front fog lamp electrical connector.
1. Remove the screws and the front fog lamp.

Installation

To install, reverse the removal procedure.
