Ford Escape: Engine System - General Information / General Procedures - Crankshaft End Play
General Equipment
Dial indicator |
Dial indicator fixture |
-
NOTE:
Refer to the appropriate Section 303-01 for the specification.
-
Position the crankshaft to the rear of the cylinder block.
-
Zero the Dial Indicator Gauge with Holding Fixture.Dial Indicator
-
Move the crankshaft to the front of the cylinder block. Note and record the crankshaft end play.
-
If the crankshaft end play exceeds the specified range, install new parts as necessary.
