Ford Escape: Pedestrian Alert System / Diagnosis and Testing - Pedestrian Alert System

Diagnostic Trouble Code (DTC) Chart

Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.
REFER to: Diagnostic Methods (100-00 General Information, Description and Operation).


Module DTC Description Action
PACM B1A01:01 Speaker #1: General Electrical Failure GO to Pinpoint Test C
PACM B1A01:11 Speaker #1: Circuit Short To Ground GO to Pinpoint Test C
PACM B1A01:12 Speaker #1: Circuit Short To Battery GO to Pinpoint Test D
PACM B1A01:13 Speaker #1: Circuit Open GO to Pinpoint Test D
PACM B1A02:01 Speaker #2: General Electrical Failure GO to Pinpoint Test C
PACM B1A02:11 Speaker #2: Circuit Short To Ground GO to Pinpoint Test C
PACM B1A02:12 Speaker #2: Circuit Short To Battery GO to Pinpoint Test D
PACM B1A02:13 Speaker #2: Circuit Open GO to Pinpoint Test D
PACM U0100:00 Lost Communication With ECM/PCM 'A': No Sub Type Information GO to Pinpoint Test E
PACM U0140:00 Lost Communication With Body Control Module: No Sub Type Information GO to Pinpoint Test F
PACM U0422:00 Invalid Data Received From Body Control Module: No Sub Type Information GO to Pinpoint Test G
PACM U201A:51 Control Module Main Calibration Data: Not Programmed GO to Pinpoint Test H
PACM U2101:00 Control Module Configuration Incompatible: No Sub Type Information GO to Pinpoint Test H
PACM U3000:41 Control Module: General Checksum Failure GO to Pinpoint Test I
PACM U3000:42 Control Module: General Memory Failure GO to Pinpoint Test I
PACM U3000:96 Control Module: Component Internal Failure GO to Pinpoint Test I
PACM U3003:16 Battery Voltage: Circuit Voltage Below Threshold GO to Pinpoint Test J
PACM U3003:17 Battery Voltage: Circuit Voltage Above Threshold GO to Pinpoint Test K

Global Customer Symptom Code (GCSC) Chart

Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.
REFER to: Diagnostic Methods (100-00 General Information, Description and Operation).


Symptom Action
Safe & Secure > Horn/Sounder > Performance > Inoperative GO to Pinpoint Test A

Symptom Chart

Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.
REFER to: Diagnostic Methods (100-00 General Information, Description and Operation).


  Symptom Chart


Condition Actions
The pedestrian alert system is inoperative   GO to Pinpoint Test A
A sounder is distorted   GO to Pinpoint Test B
Poor sounder volume   GO to Pinpoint Test A

Pinpoint Tests


PINPOINT TEST A: THE PEDESTRIAN ALERT SYSTEM IS INOPERATIVE

Normal Operation and Fault Conditions

See Pedestrian Alert System description. REFER to: Pedestrian Alert System - System Operation and Component Description (413-22 Pedestrian Alert System, Description and Operation).

The PACM receives a hot at all times voltage from the BCM . The PACM receives the ignition status message for the RUN/START or ACC input from the BCM through the GWM over the HS-CAN3 .

Possible Sources

  • Fuse
  • Communication concern
  • PACM
A1 PERFORM THE NETWORK TEST FOR ALL MODULES
  • Using a diagnostic scan tool, perform a network test.

Do all equipped modules pass the network test?
Yes GO to A2
No
REFER to: Communications Network (418-00 Module Communications Network, Diagnosis and Testing).

A2 PERFORM THE PACM (PEDESTRIAN ALERT CONTROL MODULE) MODULE SELF-TEST
  • Ignition ON.
  • Using a diagnostic scan tool, perform the PACM module self-test.
  • Check for recorded Diagnostic Trouble Codes (DTCs) from the PACM module self-test.

Are any Diagnostic Trouble Codes (DTCs) recorded?
Yes REFER to DTC Chart: PACM in this section.
No GO to A3

A3 CHECK THE SOUNDER OPERATION
  • Install a known good sounder.
    REFER to: Pedestrian Alert System Speaker (413-22 Pedestrian Alert System, Removal and Installation).
  • NOTE: Make sure the vehicle is operating in electric mode (engine not running). Operate the vehicle in a forward range between 0-30 km/h (0-8 mph) and verify whether the pedestrain alert system sounder operates.

Does the pedestrian alert system sounder operate?
Yes INSTALL a new sounder.
REFER to: Pedestrian Alert System Speaker (413-22 Pedestrian Alert System, Removal and Installation).
No REINSTALL the original sounder. INSTALL a new PACM .
REFER to: Pedestrian Alert Control Module (PACM) (413-22 Pedestrian Alert System, Removal and Installation).

PINPOINT TEST B: A SOUNDER IS DISTORTED

Normal Operation and Fault Conditions

The front and rear sounder are controlled by the PACM . Distorted sound is often caused by either debris surrounding the sounder area or a sounder.

Possible Sources

  • Debris surrounding the sounder
  • Front sounder
  • Rear sounder
B1 INSPECT THE SOUNDER
  • INSPECT and CLEAR any debris around the sounder.

Is any debris present around the sounder?
Yes CLEAR the debris from the sounder area.
No INSTALL a new sounder.
REFER to: Pedestrian Alert System Speaker (413-22 Pedestrian Alert System, Removal and Installation).

PINPOINT TEST C: B1A01:01, B1A01:11, B1A02:01, B1A02:11

Refer to Wiring Diagrams Cell 66 for schematic and connector information.

Normal Operation and Fault Conditions

The PACM controls the front and rear sounder output on hardwired circuitry and sets Diagnostic Trouble Codes (DTCs) when a circuit or sounder fault is detected.

DTC Fault Trigger Conditions

DTC Description Fault Trigger Condition
PACM B1A01:01 Speaker #1: General Electrical Failure An on-demand DTC that sets when the PACM detects the front sounder signal and return circuits are shorted together.
PACM B1A01:11 Speaker #1: Circuit Short To Ground An on-demand DTC that sets when the PACM detects the front sounder signal or return circuit is shorted to ground.
PACM B1A02:01 Speaker #2: General Electrical Failure An on-demand DTC that sets when the PACM detects the rear sounder signal and return circuits are shorted together.
PACM B1A02:11 Speaker #2: Circuit Short To Ground An on-demand DTC that sets when the PACM detects the rear sounder signal or return circuit is shorted to ground.

Possible Sources

  • Wiring, terminals or connectors
  • Front sounder
  • Rear sounder
  • PACM

Visual Inspection and Pre-checks

  • Inspect the sounder connector for corrosion (install new connector or terminals – clean module pins)
  • Inspect the sounder connector for damaged or bent pins – install new terminals/pins
  • Inspect the sounder connector for pushed-out pins – install new pins as necessary
C1 PERFORM THE PACM (PEDESTRIAN ALERT CONTROL MODULE) MODULE SELF-TEST
  • Ignition ON.
  • Using a diagnostic scan tool, perform the PACM module self-test.
  • Check for recorded Diagnostic Trouble Codes (DTCs) from the PACM module self-test.

Is DTC B1A01:01 or B1A02:01 recorded?
Yes GO to C2
No GO to C4

C2 CHECK THE SOUNDER FOR AN INTERNAL SHORT
  • Ignition OFF.
  • Disconnect Front Sounder C1945 (DTC B1A01:01).
  • Disconnect Rear Sounder C4526 (DTC B1A02:01).
  • Ignition ON.
  • Using a diagnostic scan tool, perform the PACM module self-test.
  • NOTE: DTC B1A01:01 or B1A02:01 can also be present when carrying out this step and should be disregarded at this time. Check for recorded Diagnostic Trouble Codes (DTCs) from the PACM module self-test.

Is DTC B1A01:13 or B1A02:13 recorded?
Yes INSTALL a new sounder. REFER to Removal and Installation/Pedestrian Alert System Speaker.
No GO to C3

C3 CHECK THE SOUNDER SIGNAL AND RETURN CIRCUIT FOR A SHORT TOGETHER
  • Ignition OFF.
  • Disconnect PACM C4525 .
  • Measure:
    Click to display connectors

      Front Sounder (DTC B1A01:01)


    Lead 1 Measurement / Action Lead 2
      C4525-9   C4525-8

    Click to display connectors

      Rear Sounder (DTC B1A02:01)


    Lead 1 Measurement / Action Lead 2
      C4525-11   C4525-10

Is the resistance greater than 10,000 ohms?
Yes GO to C6
No REPAIR the circuits.

C4 CHECK THE SOUNDER SIGNAL CIRCUIT FOR A SHORT TO GROUND
  • Ignition OFF.
  • Disconnect PACM C4525 .
  • Disconnect Front Sounder C1945 (DTC B1A01:11).
  • Disconnect Rear Sounder C4526 (DTC B1A02:11).
  • Measure:
    Click to display connectors

      Front Sounder (DTC B1A01:11)


    Lead 1 Measurement / Action Lead 2
      C4525-9   Ground

    Click to display connectors

      Rear Sounder (DTC B1A02:11)


    Lead 1 Measurement / Action Lead 2
      C4525-11   Ground

Is the resistance greater than 10,000 ohms?
Yes GO to C5
No REPAIR the circuit.

C5 CHECK THE SOUNDER RETURN CIRCUIT FOR A SHORT TO GROUND
  • Measure:
    Click to display connectors

      Front Sounder (DTC B1A01:11)


    Lead 1 Measurement / Action Lead 2
      C4525-8   Ground

    Click to display connectors

      Rear Sounder (DTC B1A02:11)


    Lead 1 Measurement / Action Lead 2
      C4525-10   Ground

Is the resistance greater than 10,000 ohms?
Yes GO to C6
No REPAIR the circuit.

C6 CHECK FOR CORRECT PACM (PEDESTRIAN ALERT CONTROL MODULE) OPERATION
  • Ignition OFF.
  • Disconnect and inspect the PACM and connector.
  • Repair:
    • corrosion (install new connector or terminals – clean module pins)
    • damaged or bent pins – install new terminals/pins
    • pushed-out pins – install new pins as necessary
  • Reconnect the PACM connector. Make sure it seats and latches correctly.
  • Operate the system and determine if the concern is still present.

Is the concern still present?
Yes CHECK OASIS for any applicable service articles: TSB , GSB , SSM or FSA . If a service article exists for this concern, DISCONTINUE this test and FOLLOW the service article instructions. If no service articles address this concern, INSTALL a new PACM .
REFER to: Pedestrian Alert Control Module (PACM) (413-22 Pedestrian Alert System, Removal and Installation).
No The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.
