Ford Escape 2020-2024 Service Manual / Electrical / Instrumentation and Warning Systems / Parking Aid - Vehicles With: 180 Degree Camera/360 Degree Camera/Parking Aid Camera / Diagnosis and Testing - Parking Aid

Ford Escape: Parking Aid - Vehicles With: 180 Degree Camera/360 Degree Camera/Parking Aid Camera / Diagnosis and Testing - Parking Aid

Diagnostic Trouble Code (DTC) Chart

Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.
REFER to: Diagnostic Methods (100-00 General Information, Description and Operation).


Module DTC Description Action
APIM C1001:01 Vision System Camera: General Electrical Failure GO to Pinpoint Test A
BCM B115E:01 Camera Module: General Electrical Failure GO to Pinpoint Test A
BCM B115E:02 Camera Module: General Signal Failure GO to Pinpoint Test A
BCM B115E:08 Camera Module: Bus Signal/Message Failures GO to Pinpoint Test A
BCM B115E:49 Camera Module: Internal Electronic Failure GO to Pinpoint Test A
BCM B115E:55 Camera Module: Not Configured GO to Pinpoint Test H
BCM B115E:9A Camera Module: Component or System Operating Conditions GO to Pinpoint Test A

Global Customer Symptom Code (GCSC) Chart

Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.
REFER to: Diagnostic Methods (100-00 General Information, Description and Operation).


Symptom Action
Driver Aid & Information > Exterior Camera > Performance > Appearance GO to Pinpoint Test A
Driver Aid & Information > Exterior Camera > Performance > Appearance GO to Pinpoint Test D
Driver Aid & Information > Exterior Camera > Performance > Appearance GO to Pinpoint Test E
Driver Aid & Information > Exterior Camera > Performance > Appearance GO to Pinpoint Test F
Driver Aid & Information > Exterior Camera > Performance > Appearance GO to Pinpoint Test G
Driver Aid & Information > Exterior Camera > Performance > Inaccurate GO to Pinpoint Test A
Driver Aid & Information > Exterior Camera > Performance > Inaccurate GO to Pinpoint Test B
Driver Aid & Information > Exterior Camera > Performance > Inaccurate GO to Pinpoint Test C
Driver Aid & Information > Exterior Camera > Performance > Inaccurate GO to Pinpoint Test D
Driver Aid & Information > Exterior Camera > Performance > Inaccurate GO to Pinpoint Test E
Driver Aid & Information > Exterior Camera > Performance > Inoperative GO to Pinpoint Test A
Driver Aid & Information > Exterior Camera > Display > Appearance GO to Pinpoint Test A
Driver Aid & Information > Exterior Camera > Display > Appearance GO to Pinpoint Test B
Driver Aid & Information > Exterior Camera > Display > Appearance GO to Pinpoint Test C
Driver Aid & Information > Exterior Camera > Display > Appearance GO to Pinpoint Test D
Driver Aid & Information > Exterior Camera > Display > Appearance GO to Pinpoint Test E
Driver Aid & Information > Exterior Camera > Display > Appearance GO to Pinpoint Test G

Symptom Chart(s)

Rear Only Parking Aid Camera

Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.
REFER to: Diagnostic Methods (100-00 General Information, Description and Operation).

Condition Actions
The rear parking aid camera is inoperative   GO to Pinpoint Test A
The audio system displays REAR VIDEO CAMERA IS UNAVAILABLE or CAMERA IS UNAVAILABLE PLEASE CONTACT YOUR DEALERSHIP and a black screen/no image   GO to Pinpoint Test A
Static/flashing/blinking/flickering/scrolling or rolling image/screen/scrolling horizontal lines   GO to Pinpoint Test B
Poor image quality (foggy/cloudy/fuzzy/blurry/hazy image or moisture/water in lens or black spots)   GO to Pinpoint Test B
Frozen screen or slow screen transitions
REFER to: Information and Entertainment System (415-00 Information and Entertainment System - General Information, Diagnosis and Testing).
Manual zoom function is inoperative   GO to Pinpoint Test E
Visual park aid alert is inoperative   GO to Pinpoint Test C
Active guidelines are inoperative or do no operate correctly   GO to Pinpoint Test D
Fixed guidelines are inoperative or do not operate correctly   GO to Pinpoint Test D
The video delay feature is inoperative or does not operate correctly   GO to Pinpoint Test F
Video image is upside down   GO to Pinpoint Test G
All other image concerns   GO to Pinpoint Test A

Pinpoint Test(s)


PINPOINT TEST A: THE REAR PARKING AID CAMERA IS INOPERATIVE OR DOES NOT OPERATE CORRECTLY

Refer to Wiring Diagrams Cell 145 for schematic and connector information.

Normal Operation and Fault Conditions

REFER to: Parking Aid - System Operation and Component Description (413-13B Parking Aid - Vehicles With: 180 Degree Camera/360 Degree Camera/Parking Aid Camera, Description and Operation).

DTC Fault Trigger Conditions

DTC Description Fault Trigger Condition
APIM C1001:01 Vision System Camera: General Electrical Failure A continuous and on-demand DTC that sets in the APIM when an expected video signal is not received from the rear parking aid camera.
BCM B115E:01 Camera Module: General Electrical Failure A continuous memory and on-demand DTC that sets in the BCM when an internal electrical failure is detected from the rear parking aid camera.
BCM B115E:02 Camera Module: General Signal Failure A continuous memory and on-demand DTC that sets in the BCM when invalid LIN data is received from the rear parking aid camera.
BCM B115E:08 Camera Module: Bus Signal/Message Failures A continuous memory and on-demand DTC that sets in the BCM when messages are missing on the LIN circuit.
BCM B115E:49 Camera Module: Internal Electronic Failure A continuous memory and on-demand DTC that sets in the BCM when an internal fault in the rear parking aid camera is detected.
BCM B115E:9A Camera Module: Component or System Operating Conditions An on-demand DTC that sets in the BCM when an fault in the rear parking aid camera is detected.

Possible Sources

  • Wiring, terminals or connectors
  • Fuse
  • Rear parking aid camera
  • BCM concern
  • TR input concern
  • Audio system display
  • Communication concern
  • LIN concern
A1 CHECK AND CLEAN THE REAR VIDEO CAMERA LENS
  • Clean and make sure the rear parking aid camera lens is clear of any debris.
  • Ignition ON.
  • Test the system and verify the parking aid camera image.

Is the parking aid camera concern still present?
Yes GO to A2
No The system is operating correctly at this time. The concern was caused by a dirty parking aid camera lens.

A2 CHECK FOR CORRECT GEAR INPUT
  • While monitoring the reversing lamps, move the selector lever through the entire range.

Do the reversing lamps illuminate only in reverse?
Yes GO to A3
No
REFER to: Reversing Lamps (417-01 Exterior Lighting, Diagnosis and Testing).

A3 CHECK THE BCM (BODY CONTROL MODULE) CONTINUOUS MEMORY DIAGNOSTIC TROUBLE CODES (CMDTCS)
  • Using a diagnostic scan tool, check the BCM Continuous Memory Diagnostic Trouble Codes (CMDTCs).

Are any Continuous Memory Diagnostic Trouble Codes (CMDTCs) present?
Yes For BCM Diagnostic Trouble Codes (DTCs) B115E:01, B115E:02, B115E:08, B115E:49 or B115E:9A, GO to A7
For all other DTCs (diagnostic trouble codes), REFER to the DTC Chart in this section.
No GO to A4

A4 PERFORM A NETWORK TEST
  • Using a diagnostic scan tool, perform a network test.

Do all modules pass the network test?
Yes GO to A5
No
REFER to: Communications Network (418-00 Module Communications Network, Diagnosis and Testing).

A5 CHECK FOR DIAGNOSTIC TROUBLE CODES (DTCS) FROM THE APIM (SYNC MODULE) SELF-TEST
  • Using a diagnostic scan tool, perform the APIM self-test.

Are any Diagnostic Trouble Codes (DTCs) retrieved?
Yes For DTC C1001:01, GO to A6
For all other Diagnostic Trouble Codes (DTCs),
REFER to: Information and Entertainment System (415-00 Information and Entertainment System - General Information, Diagnosis and Testing).
No GO to A6

A6 CHECK THE VIDEO DISPLAY
  • Observe the audio system display while placing the selector lever in reverse.
  • Wait 30 seconds.

Does the display switch to parking aid camera mode and display REAR VIDEO CAMERA IS UNAVAILABLE PLEASE CONTACT YOUR DEALERSHIP?
Yes GO to A7
No DIAGNOSE the audio system display.
REFER to: Information and Entertainment System (415-00 Information and Entertainment System - General Information, Diagnosis and Testing).

A7 CHECK THE VOLTAGE TO THE CAMERA

NOTE: Before disconnecting the rear parking aid camera, verify that the connector is properly seated and latched.

  • Ignition OFF.
  • Disconnect Rear Parking Aid Camera C4357 .
  • Ignition ON.
  • Measure:
    Click to display connectors
    Positive Lead Measurement / Action Negative Lead
      C4357-1   Ground

Is the voltage greater than 11 volts?
Yes GO to A8
No INSPECT BJB fuse 25 (10A). If the fuse is OK, repair the circuit for an open. If the fuse is not OK, REFER to the Wiring Diagrams manual to identify the possible causes of the short circuit.

A8 CHECK FOR GROUND TO THE CAMERA
  • Ignition OFF.
  • Measure:
    Click to display connectors
    Positive Lead Measurement / Action Negative Lead
      C4357-5   Ground

Is the resistance less than 3 ohms?
Yes GO to A9
No REPAIR the circuit.

A9 CHECK THE VIDEO SIGNAL CIRCUITS FOR A SHORT TO VOLTAGE
  • Disconnect APIM C2383A .
  • Ignition ON.
  • Measure:
    Click to display connectors
    Positive Lead Measurement / Action Negative Lead
      C4357-3   Ground
      C4357-4   Ground

Is any voltage present?
Yes REPAIR the circuit in question.
No GO to A10

A10 CHECK THE VIDEO SIGNAL CIRCUITS FOR A SHORT TO GROUND
  • Ignition OFF.
  • Measure:
    Click to display connectors
    Positive Lead Measurement / Action Negative Lead
      C4357-3   Ground
      C4357-4   Ground

Are the resistances greater than 10,000 ohms?
Yes GO to A11
No REPAIR the circuit in question.

A11 CHECK THE VIDEO SIGNAL CIRCUITS FOR A SHORT TO THE VIDEO SHIELD
  • Measure:
    Click to display connectors

      Non-chassis cab


    Positive Lead Measurement / Action Negative Lead
      C4357-3   C4357-5
      C4357-4   C4357-5

Are the resistances greater than 10,000 ohms?
Yes GO to A12
No REPAIR the circuit in question.

A12 CHECK THE VIDEO SIGNAL CIRCUITS FOR AN OPEN
  • Connect a fused jumper wire:
    Click to display connectors
    Positive Lead Measurement / Action Negative Lead
      C4357-3   C4357-4
  • Measure:
    Click to display connectors
    Positive Lead Measurement / Action Negative Lead
      C2383A-14   C2383A-15

Is the resistance less than 3 ohms?
Yes Remove the fused jumper wire, GO to A14
No Remove the fused jumper wire, GO to A13

A13 CHECK THE VIDEO (+) SIGNAL CIRCUIT FOR AN OPEN
  • Measure:
    Click to display connectors
    Positive Lead Measurement / Action Negative Lead
      C2383A-14   C4357-4

Is the resistance less than 3 ohms?
Yes REPAIR the video (-) signal circuit.
No REPAIR the video (+) signal circuit.

A14 CHECK THE LIN (LOCAL INTERCONNECT NETWORK) CIRCUIT FOR A SHORT TO VOLTAGE
  • Disconnect BCM C2280F .
  • Disconnect DC / AC inverter C2293 .
  • Ignition ON.
  • Measure:
    Click to display connectors
    Positive Lead Measurement / Action Negative Lead
      C2280F-59   Ground

Is any voltage present?
Yes REPAIR the circuit.
No GO to A15

A15 CHECK THE LIN (LOCAL INTERCONNECT NETWORK) CIRCUIT FOR AN OPEN
  • Ignition OFF.
  • Measure:
    Click to display connectors
    Positive Lead Measurement / Action Negative Lead
      C2280F-59   C4357-2

Is resistance less than 3 ohms ?
Yes GO to A16
No REPAIR the circuit.

A16 CHECK THE LIN (LOCAL INTERCONNECT NETWORK) CIRCUIT FOR A SHORT TO GROUND
  • Measure:
    Click to display connectors
    Positive Lead Measurement / Action Negative Lead
      C2280F-59   Ground

Is resistance greater than 10,000 ohms?
Yes GO to A17
No REPAIR the circuit.

A17 CHECK FOR REAR PARKING AID CAMERA OPERATION
  • Ignition OFF.
  • Disconnect and inspect the Rear Parking Aid Camera connector and related in-line connectors.
  • Repair:
    • corrosion (install new connector or terminals – clean module pins)
    • damaged or bent pins – install new terminals/pins
    • pushed-out pins – install new pins as necessary
  • Reconnect the rear parking aid camera connector. Make sure it seats and latches correctly.
  • Operate the system and determine if the concern is still present.

Is the concern still present?
Yes CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW the TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new camera.
REFER to: Rear Parking Aid Camera (413-13B Parking Aid - Vehicles With: 180 Degree Camera/360 Degree Camera/Parking Aid Camera, Removal and Installation). If the concern is still present after camera replacement, GO to A18
No The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. ADDRESS the root cause of any connector or pin issues.

A18 CHECK FOR CORRECT BCM (BODY CONTROL MODULE) OPERATION
  • Ignition OFF.
  • Disconnect and inspect the BCM connectors and related in-line connectors.
  • Repair:
    • corrosion (install new connector or terminals – clean module pins)
    • damaged or bent pins – install new terminals/pins
    • pushed-out pins – install new pins as necessary
  • Reconnect the BCM connectors. Make sure they seat and latch correctly.
  • Operate the system and determine if the concern is still present.

Is the concern still present?
Yes CHECK OASIS for any applicable service articles: TSB , GSB , SSM or FSA . If a service article exists for this concern, DISCONTINUE this test and FOLLOW the service article instructions. If no service articles address this concern, INSTALL a new BCM. Refer to the appropriate Removal and Installation procedure in Section 419-10.
No The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. ADDRESS the root cause of any connector or pin issues.

PINPOINT TEST B: POOR IMAGE QUALITY

Refer to Wiring Diagrams Cell 145 for schematic and connector information.

Normal Operation and Fault Conditions

REFER to: Parking Aid - System Operation and Component Description (413-13B Parking Aid - Vehicles With: 180 Degree Camera/360 Degree Camera/Parking Aid Camera, Description and Operation).

Possible Sources

  • Dirty or scratched camera lens
  • Wiring, terminals or connectors
  • Rear parking aid camera
  • APIM
  • Interference from other sources

Visual Inspection and Pre-checks

  • Make sure the rear video camera lens is clear of any debris.
B1 CHECK AND CLEAN THE CAMERA LENS
  • Clean and make sure the rear parking aid camera lens is clear of any debris and scratches.
  • Test the rear parking aid camera system while observing the video camera image.

Is the concern still present?
Yes GO to B2
No The system is operating correctly at this time. The concern may have been caused by dirt or debris on the camera lens or intermittent electromagnetic interference from an outside source.

B2 CHECK THE VOLTAGE TO THE REAR CAMERA
  • Ignition OFF.
  • Disconnect Rear Parking Aid Camera C4357 .
  • Ignition ON.
  • Measure:
    Click to display connectors
    Positive Lead Measurement / Action Negative Lead
      C4357-1   Ground

Is the voltage greater than 11 volts?
Yes GO to B3
No INSPECT BJB fuse 25 (10A). If the fuse is OK, repair the circuit for an open. If the fuse is not OK, REFER to the Wiring Diagrams manual to identify the possible causes of the short circuit.

B3 CHECK THE CAMERA GROUND CIRCUIT
  • Measure:
    Click to display connectors
    Positive Lead Measurement / Action Negative Lead
      C4357-5   Ground

Is the resistance less than 3 ohms?
Yes GO to B4
No REPAIR the circuit.

B4 CHECK THE VIDEO SIGNAL AND SHIELD CIRCUITS FOR A SHORT TO VOLTAGE
  • Disconnect APIM C2383A .
  • Ignition ON.
  • Measure:
    Click to display connectors
    Positive Lead Measurement / Action Negative Lead
      C4357-3   Ground
      C4357-4   Ground
      C4357-5   Ground

Is any voltage present?
Yes REPAIR the circuit in question.
No GO to B5

B5 CHECK THE VIDEO SIGNAL CIRCUITS FOR A SHORT TO GROUND
  • Ignition OFF.
  • Measure:
    Click to display connectors
    Positive Lead Measurement / Action Negative Lead
      C4357-3   Ground
      C4357-4   Ground

Are the resistances greater than 10,000 ohms?
Yes GO to B6
No REPAIR the circuit in question.

B6 CHECK THE VIDEO SIGNAL CIRCUITS FOR A SHORT TO THE VIDEO SHIELD
  • Measure:
    Click to display connectors
    Positive Lead Measurement / Action Negative Lead
      C4357-3   C4357-5
      C4357-4   C4357-5

Are the resistances greater than 10,000 ohms?
Yes GO to B7
No REPAIR the circuit in question.

B7 CHECK VIDEO SIGNAL CIRCUITS FOR AN OPEN
  • Measure:
    Click to display connectors
    Positive Lead Measurement / Action Negative Lead
      C4357-4   C2383A-14
      C4357-3   C2383A-15

Are the resistances less than 3 ohms?
Yes GO to B8
No REPAIR the circuit in question.

B8 CHECK THE VIDEO SHIELD CIRCUIT FOR AN OPEN
  • Measure:
    Click to display connectors
    Positive Lead Measurement / Action Negative Lead
      C4357-5   C2383A-33

Is the resistance less than 3 ohms?
Yes GO to B9
No REPAIR the circuit

B9 CHECK FOR CORRECT PARKING AID CAMERA OPERATION
  • Ignition OFF.
  • Disconnect and inspect the rear parking aid camera connector and related in-line connectors.
  • Repair:
    • corrosion (install new connector or terminals – clean module pins)
    • damaged or bent pins – install new terminals/pins
    • pushed-out pins – install new pins as necessary
  • Reconnect the rear parking aid camera connector. Make sure it seats and latches correctly.
  • Operate the system and determine if the concern is still present.

Is the concern still present?
Yes CHECK OASIS for any applicable service articles: TSB , GSB , SSM or FSA . If a service article exists for this concern, DISCONTINUE this test and FOLLOW the service article instructions. If no service articles address this concern, INSTALL a new camera.
REFER to: Rear Parking Aid Camera (413-13B Parking Aid - Vehicles With: 180 Degree Camera/360 Degree Camera/Parking Aid Camera, Removal and Installation).
No The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. ADDRESS the root cause of any connector or pin issues.

PINPOINT TEST C: THE VISUAL PARK AID ALERT IS INOPERATIVE

Normal Operation and Fault Conditions

REFER to: Parking Aid - System Operation and Component Description (413-13B Parking Aid - Vehicles With: 180 Degree Camera/360 Degree Camera/Parking Aid Camera, Description and Operation).

Possible Sources

  • Rear parking aid camera
  • PAM concern
  • BCM concern

Visual Inspection and Pre-checks

  • If the rear parking aid camera is not configured after replacement, some video functions will be inoperative. Turn the ignition on for 5 minutes to allow the camera/BCM calibration to complete.
C1 PERFORM A NETWORK TEST
  • Ignition ON.
  • Using a diagnostic scan tool, perform a network test.

Do all modules pass the network test?
Yes GO to C2
No
REFER to: Communications Network (418-00 Module Communications Network, Diagnosis and Testing).

C2 CHECK THE PAM (PARKING ASSIST CONTROL MODULE) CONTINUOUS MEMORY DIAGNOSTIC TROUBLE CODES (CMDTCS)
  • Using a diagnostic scan tool, check the PAM Continuous Memory Diagnostic Trouble Codes (CMDTCs).

Are any Continuous Memory Diagnostic Trouble Codes (CMDTCs) present?
Yes
REFER to: Parking Aid (413-13A Parking Aid - Vehicles With: Rear Parking Aid, Diagnosis and Testing).
No GO to C3

C3 CHECK THE BCM (BODY CONTROL MODULE) CONTINUOUS MEMORY DIAGNOSTIC TROUBLE CODES (CMDTCS)
  • Using a diagnostic scan tool, check the BCM Continuous Memory Diagnostic Trouble Codes (CMDTCs).

Continuous Memory Diagnostic Trouble Codes (CMDTCs) present?
Yes REFER to BCM DTC Chart in this section.
No GO to C4

C4 CHECK FOR CORRECT VIDEO CAMERA OPERATION
  • Ignition ON.
  • Disconnect and inspect the rear parking aid camera connector and related in-line connectors.
  • Repair:
    • corrosion (install new connector or terminals – clean module pins)
    • damaged or bent pins – install new terminals/pins
    • pushed-out pins – install new pins as necessary
  • Reconnect the rear parking aid camera connector. Make sure it seats and latches correctly.
  • Operate the system and determine if the concern is still present.

Is the concern still present?
Yes CHECK OASIS for any applicable service articles: TSB , GSB , SSM or FSA . If a service article exists for this concern, DISCONTINUE this test and FOLLOW the service article instructions. If no service articles address this concern, INSTALL a new camera.
REFER to: Rear Parking Aid Camera (413-13B Parking Aid - Vehicles With: 180 Degree Camera/360 Degree Camera/Parking Aid Camera, Removal and Installation).
No The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. ADDRESS the root cause of any connector or pin issues.

PINPOINT TEST D: THE GUIDELINES ARE INOPERATIVE OR DO NOT OPERATE CORRECTLY

Normal Operation and Fault Conditions

REFER to: Parking Aid - System Operation and Component Description (413-13B Parking Aid - Vehicles With: 180 Degree Camera/360 Degree Camera/Parking Aid Camera, Description and Operation).

Possible Sources

  • Communication network concern
  • Video camera not configured after replacement
  • Liftgate position ajar concern
  • Steering wheel position data concern (active guidelines only)
  • Rear parking aid camera
  • ABS module concern (active guidelines only)
  • PSCM concern (active guidelines only)
  • APIM

Visual Inspection and Pre-checks

  • Verify the inoperative feature is enabled in the settings menu. Refer to the Owner's Literature.
  • Verify the liftgate is fully closed.
  • For active guideline concerns, verify the concern was not caused by the steering wheel being in the straight ahead position. Active guidelines are not displayed unless the steering wheel is rotated.
D1 PERFORM THE PARKING AID CAMERA INITIALIZATION
  • Ignition ON.
  • Using a diagnostic scan tool, perform the parking aid camera initialization.
    REFER to: Parking Aid Camera Initialization (413-13B Parking Aid - Vehicles With: 180 Degree Camera/360 Degree Camera/Parking Aid Camera, General Procedures).

Do the guidelines operate correctly after performing the camera initialization?
Yes The system is operating correctly at this time.
No GO to D2

D2 PERFORM A NETWORK TEST
  • Ignition ON.
  • Using a diagnostic scan tool, perform a network test.

Do all modules pass the network test?
Yes If the vehicle is equipped with factory trailer tow, GO to D3
If the vehicle is not equipped with factory trailer tow, GO to D4
No
REFER to: Communications Network (418-00 Module Communications Network, Diagnosis and Testing).

D3 CHECK THE DIAGNOSTIC TROUBLE CODES (DTCS) FROM THE TRM (TRAILER MODULE) SELF-TEST
  • Using a diagnostic scan tool, perform the TRM self-test.

Are any TRM Diagnostic Trouble Codes (DTCs) retrieved?
Yes
REFER to: Trailer Lamps (417-01 Exterior Lighting, Diagnosis and Testing).
No GO to D4

D4 CHECK THE DIAGNOSTIC TROUBLE CODES (DTCS) FROM THE BCM (BODY CONTROL MODULE) SELF-TEST
  • Using a scan tool, perform the BCM self-test.

Are any BCM Diagnostic Trouble Codes (DTCs) retrieved?
Yes REFER to the BCM DTC Chart in this section.
No For an active guideline concern, GO to D5
For a fixed guideline concern, GO to D7

D5 CHECK THE DIAGNOSTIC TROUBLE CODES (DTCS) FROM THE ABS (ANTI-LOCK BRAKE SYSTEM) MODULE SELF-TEST
  • Using a diagnostic scan tool, perform the ABS module self-test.

Are any ABS module Diagnostic Trouble Codes (DTCs) retrieved?
Yes
REFER to: Anti-Lock Brake System (ABS) and Stability Control (206-09 Anti-Lock Brake System (ABS) and Stability Control, Diagnosis and Testing).
No GO to D6

D6 CHECK THE DIAGNOSTIC TROUBLE CODES (DTCS) FROM THE PSCM (POWER STEERING CONTROL MODULE) SELF-TEST
  • Using a diagnostic scan tool, perform the PSCM self-test.

Are any PSCM Diagnostic Trouble Codes (DTCs) retrieved?
Yes
REFER to: Steering Wheel and Column Electrical Components (211-05 Steering Wheel and Column Electrical Components, Diagnosis and Testing).
No GO to D7

D7 CHECK FOR CORRECT REAR PARKING AID CAMERA OPERATION
  • Ignition OFF.
  • Disconnect and inspect the rear parking aid camera connector.
  • Repair:
    • corrosion (install new connector or terminals – clean module pins)
    • damaged or bent pins – install new terminals/pins
    • pushed-out pins – install new pins as necessary
  • Reconnect the rear parking aid camera connector. Make sure it seats and latches correctly.
  • Operate the system and determine if the concern is still present.

Is the concern still present?
Yes CHECK OASIS for any applicable service articles: TSB , GSB , SSM or FSA . If a service article exists for this concern, DISCONTINUE this test and FOLLOW the service article instructions. If no service articles address this concern, INSTALL a new rear parking aid camera.
REFER to: Rear Parking Aid Camera (413-13B Parking Aid - Vehicles With: 180 Degree Camera/360 Degree Camera/Parking Aid Camera, Removal and Installation).
If the concern is still present after camera replacement, GO to D8
No The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. ADDRESS the root cause of any connector or pin issues.

D8 CHECK FOR CORRECT BCM (BODY CONTROL MODULE) OPERATION
  • Ignition OFF.
  • Disconnect and inspect all BCM connectors.
  • Repair:
    • corrosion (install new connector or terminals – clean module pins)
    • damaged or bent pins – install new terminals/pins
    • pushed-out pins – install new pins as necessary
  • Reconnect all BCM connectors. Make sure they seat and latch correctly.
  • Operate the system and determine if the concern is still present.

Is the concern still present?
Yes CHECK OASIS for any applicable service articles: TSB , GSB , SSM or FSA . If a service article exists for this concern, DISCONTINUE this test and FOLLOW the service article instructions. If no service articles address this concern, INSTALL a new BCM. Refer to the appropriate Removal and Installation procedure in Section 419-10.
No The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. ADDRESS the root cause of any connector or pin issues.

PINPOINT TEST E: THE MANUAL ZOOM IS INOPERATIVE

Normal Operation and Fault Conditions

REFER to: Parking Aid - System Operation and Component Description (413-13B Parking Aid - Vehicles With: 180 Degree Camera/360 Degree Camera/Parking Aid Camera, Description and Operation).

Possible Sources

  • Communication network concern
  • Video camera not configured after replacement
  • Rear parking aid camera
  • APIM concern

Visual Inspection and Pre-checks

  • If the rear parking aid camera is not configured after replacement, some video functions will be inoperative. Verify the rear video camera configuration using the diagnostic scan tool.
E1 PERFORM A NETWORK TEST
  • Ignition ON.
  • Using a diagnostic scan tool, perform a network test.

Do all modules pass the network test?
Yes GO to E2
No See the Symptom Chart: Communication Network.
REFER to: Communications Network (418-00 Module Communications Network, Diagnosis and Testing).

E2 CHECK FOR RECORDED DIAGNOSTIC TROUBLE CODES (DTCS) FROM THE APIM (SYNC MODULE) SELF-TEST
  • Using a diagnostic scan tool, perform the APIM self-test.

Are any Diagnostic Trouble Codes present?
Yes For DTC C1001:01, GO to Pinpoint Test A
For all other Diagnostic Trouble Codes (DTCs), see the APIM DTC Chart.
REFER to: Information and Entertainment System (415-00 Information and Entertainment System - General Information, Diagnosis and Testing).
No GO to E3

E3 CHECK FOR CORRECT REAR PARKING AID CAMERA OPERATION
  • Ignition OFF.
  • Disconnect and inspect the rear parking aid camera connector.
  • Repair:
    • corrosion (install new connector or terminals – clean module pins)
    • damaged or bent pins – install new terminals/pins
    • pushed-out pins – install new pins as necessary
  • Reconnect the rear parking aid camera connector. Make sure it seats and latches correctly.
  • Operate the system and determine if the concern is still present.

Is the concern still present?
Yes CHECK OASIS for any applicable service articles: TSB , GSB , SSM or FSA . If a service article exists for this concern, DISCONTINUE this test and FOLLOW the service article instructions. If no service articles address this concern, INSTALL a new rear parking aid camera.
REFER to: Rear Parking Aid Camera (413-13B Parking Aid - Vehicles With: 180 Degree Camera/360 Degree Camera/Parking Aid Camera, Removal and Installation).
No The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. ADDRESS the root cause of any connector or pin issues.

PINPOINT TEST F: THE VIDEO DELAY IS INOPERATIVE OR DOES NOT OPERATE CORRECTLY

Normal Operation and Fault Conditions

REFER to: Parking Aid - System Operation and Component Description (413-13B Parking Aid - Vehicles With: 180 Degree Camera/360 Degree Camera/Parking Aid Camera, Description and Operation).

Possible Sources

  • Communication network concern
  • The rear parking aid camera delay feature is disabled
  • TR input concern
  • APIM concern

Visual Inspection and Pre-checks

  • Verify the video delay feature is turned on in the settings menu. Refer to the Owner's Literature.
F1 PERFORM A NETWORK TEST
  • Ignition ON.
  • Using a diagnostic scan tool, perform a network test.

Do all modules pass the network test?
Yes GO to F2
No See the Symptom Chart: Communication Network.
REFER to: Communications Network (418-00 Module Communications Network, Diagnosis and Testing).

F2 CHECK THE FOR CORRECT GEAR INPUT
  • Apply the parking brake.
  • While monitoring the reversing lamps, shift the transmission through all gears.

Do the reversing lamps illuminate only when reverse gear is selected?
Yes GO to F3
No DIAGNOSE the reversing lamps.
REFER to: Reversing Lamps (417-01 Exterior Lighting, Diagnosis and Testing).

F3 CHECK FOR DIAGNOSTIC TROUBLE CODES (DTCS) FROM THE APIM (SYNC MODULE) SELF-TEST
  • Using a diagnostic scan tool, perform the APIM self-test.

Are any Diagnostic Trouble Codes (DTCs) retrieved?
Yes • For DTC C1001:01, GO to Pinpoint Test A
• For all other Diagnostic Trouble Codes (DTCs), see the APIM DTC Chart.
REFER to: Information and Entertainment System (415-00 Information and Entertainment System - General Information, Diagnosis and Testing).
No GO to F4

F4 CHECK FOR CORRECT APIM (SYNC MODULE) OPERATION
  • Ignition OFF.
  • Disconnect and inspect the APIM connectors.
  • Repair:
    • corrosion (install new connector or terminals – clean module pins)
    • damaged or bent pins – install new terminals/pins
    • pushed-out pins – install new pins as necessary
  • Reconnect the APIM connectors. Make sure they seat and latch correctly.
  • Operate the system and determine if the concern is still present.

Is the concern still present?
Yes CHECK OASIS for any applicable service articles: TSB , GSB , SSM or FSA . If a service article exists for this concern, DISCONTINUE this test and FOLLOW the service article instructions. If no service articles address this concern,
   VIN required to access Guided Routine (APIM)
No The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. ADDRESS the root cause of any connector or pin issues.

PINPOINT TEST G: VIDEO IMAGE IS UPSIDE DOWN

Normal Operation and Fault Conditions

REFER to: Parking Aid - System Operation and Component Description (413-13B Parking Aid - Vehicles With: 180 Degree Camera/360 Degree Camera/Parking Aid Camera, Description and Operation).

Possible Sources

  • Rear parking aid camera
G1 CHECK FOR REAR PARKING AID CAMERA OPERATION
  • Ignition OFF.
  • Disconnect and inspect the Rear Parking Aid Camera connector and related in-line connectors.
  • Repair:
    • corrosion (install new connector or terminals – clean module pins)
    • damaged or bent pins – install new terminals/pins
    • pushed-out pins – install new pins as necessary
  • Reconnect the rear parking aid camera connector. Make sure it seats and latches correctly.
  • Operate the system and determine if the concern is still present.

Is the concern still present?
Yes CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW the TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new camera.
REFER to: Rear Parking Aid Camera (413-13B Parking Aid - Vehicles With: 180 Degree Camera/360 Degree Camera/Parking Aid Camera, Removal and Installation).
No The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. ADDRESS the root cause of any connector or pin issues.

PINPOINT TEST H: B115E:55

Normal Operation and Fault Conditions

DTC Fault Trigger Conditions

DTC Description Fault Trigger Condition
BCM B115E:55 Camera Module: Not Configured Sets in continuous memory and on-demand in the BCM when the rear parking aid camera is not configured.

Possible Sources

  • Rear parking aid camera initialization
H1 PERFORM THE PARKING AID CAMERA INITIALIZATION USING A DIAGNOSTIC SCAN TOOL
  • Ignition ON.
  • Perform the parking aid camera initialization procedure.

Did the parking aid camera initialization procedure complete successfully?
Yes The system is operating correctly at this time.
No REFER symptom chart in this section to diagnosis the rear parking aid camera symptom.


    Description and Operation - Parking Aid - System Operation and Component Description

    S..

    General Procedures - Parking Aid Camera Initialization

    NOTE: On vehicles equipped with Trailer Reverse Guidance (TRG) complete this procedure and also perform the Trailer Reverse Guidance camera alignment...

    Other information:

    Ford Escape 2020-2024 Owners Manual: Liftgate – Troubleshooting


    Liftgate – Warning Lamps Illuminates when the liftgate is not completely closed. Liftgate – Information Messages Liftgate – Frequently Asked Questions Why won't my power liftgate function? Make sure the transmission is in park (P), ensure nothing is obstructing the liftgate path and there is not excessive weight on the liftgate...

    Ford Escape 2020-2024 Service Manual: General Procedures - Clockspring Adjustment


    Special Tool(s) / General Equipment Adhesive Tape   WARNING: If the clockspring is not correctly centralized, it may fail prematurely. If in doubt, repeat the centralizing procedure. Failure to follow these instructions may increase the risk of serious personal injury or death in a crash...

    Categories

    Fastening the Seatbelts

    Ford Escape. Fastening the Seatbelts

    Insert the belt tongue into the proper buckle, the buckle closest to the direction the tongue is coming from, until it engages.

    read more

    Copyright © 2024 www.fordescape4.com
