| DTC |
Description |
Fault Trigger Condition |
| PCM P00FE:00 |
EVAP System Tank Vapor Line Restricted/Blocked: No Sub Type Information |
Sets when the PCM detects a restriction and the counter is incremented
and the counter reaches a calibrated number of completions.
The PCM monitors the EVAP
system for a restricted fuel vapor tube between the fuel tank pressure
sensor and the fuel tank. During the initial phase of the EVAP monitor,
the PCM closes the canister vent and a vacuum develops in the fuel
vapor tubes and lines and in the fuel tank. The PCM
monitors the fuel tank pressure sensor to determine the amount of
vacuum and how quickly the vacuum increases. The rate at which the
vacuum increases is compared to an expected value. If the vacuum
increases quicker than expected, a restricted fuel vapor tube is
suspected and an intrusive test is carried out in the final phase of the
EVAP monitor.
Check the fuel vapor tube for a restriction between the fuel tank
pressure sensor and the fuel tank.
|
| PCM P043E:00 |
EVAP System Leak Detection Reference Orifice Low Flow: No Sub Type Information |
Sets when the PCM detects an EVAP leak detection control module internal concern.
|
| PCM P043F:00 |
EVAP System Leak Detection Reference Orifice High Flow: No Sub Type Information |
Sets when the PCM detects an EVAP leak detection control module internal concern.
|
| PCM P0442:00 |
EVAP System Leak Detected (small leak): No Sub Type Information |
Sets when the PCM detects a small fuel vapor leak by the EVAP running
loss monitor test.
Check for a missing fuel filler cap or the integrity of the cap (if
equipped).
Verify the
capless fuel tank filler pipe is sealed correctly (if equipped). Install
and remove the supplemental fueling adapter five times in the capless
fuel tank filler pipe to clear debris on the seal. Refer to the Owner
Literature for the location of the supplemental fueling adapter in the
vehicle. Check for loose or damaged vapor hoses.
Visually inspect the EVAP canister inlet port, EVAP canister vent valve
filter, and canister vent hose assembly for contamination or debris.
|
| PCM P0443:00 |
EVAP System Purge Control Valve 'A' Circuit: No Sub Type Information |
Sets when the PCM detects the signal moves outside the minimum or
maximum limit for the commanded state.
To verify normal function, monitor the EVMV PID or EVAP canister
pressure PID and the signal voltage ( PCM control side). With the valve
closed, the EVMV indicates 0 mA (0% duty cycle for EVAP
canister pressure) and voltage approximately equal to battery voltage.
When the valve is commanded fully open, EVMV indicates 1,000 mA (100%
duty cycle for EVAP canister pressure) and a voltage drop of 3 volts
minimum is normal.
|
| PCM P0446:00 |
EVAP System Vent Control Circuit: No Sub Type Information |
Sets when the PCM detects the signal moves outside the minimum or
maximum allowable calibrated parameters for a specified EVAP canister
vent valve duty cycle by PCM command.
To verify normal function, monitor the EVAP canister vent valve signal
PID
EVAP canister vent and the signal voltage ( PCM control side). With the
valve open, EVAP
canister vent indicates 0% duty cycle and a voltage approximately
equal to battery voltage. When the valve is commanded fully closed, EVAP
canister vent indicates 100% duty cycle, and a minimum voltage drop of 4
volts is normal.
|
| PCM P0451:00 |
EVAP System Pressure Sensor/Switch 'A' Circuit Range/Performance: No Sub Type Information |
Sets when the PCM
detects a fuel tank pressure sensor range (offset) concern is
detected. The fuel tank pressure sensor output is offset by greater than
1.7 inches of water or less than -1.7 inches of water.
With the fuel tank pressure (FTP) sensor at atmospheric pressure, the FTP PID
normally indicates 0 inches of water. Remove the fuel filler cap or,
for vehicles with a capless fuel filler pipe, install the supplemental
refueling adaptor provided with the vehicle to open the capless fuel
tank filler pipe. After installing the supplemental refueling adaptor or
removing the fuel filler cap, wait one minute to allow the pressure in
the fuel tank to equalize with the ambient air pressure before accessing
the PID .
|
| PCM P0452:00 |
EVAP System Pressure Sensor/Switch 'A' Circuit Low: No Sub Type Information |
Sets when the PCM detects the fuel tank pressure sensor signal average
drops below a minimum allowable calibrated parameter.
A FTP voltage PID reading less than 0.22 volt in ignition ON, engine
OFF or ignition ON, engine running indicates a concern is present.
|
| PCM P0453:00 |
EVAP System Pressure Sensor/Switch 'A' Circuit High: No Sub Type Information |
Sets when the PCM detects the fuel tank pressure sensor signal average
jumps above a minimum allowable calibrated parameter.
A FTP voltage PID reading greater than 4.85 volt in ignition ON, engine
OFF or ignition ON, engine running indicates a concern is present.
|
| PCM P0454:00 |
EVAP System Pressure Sensor/Switch 'A' Circuit Intermittent: No Sub Type Information |
Sets when the PCM detects the fuel tank pressure changes greater than
14 inches of water in 0.10 seconds.
Monitor the FTP PID and note if it changes from greater than 15 inches
of water to less than minus (-) 15 inches of water often in 1 minute.
|
| PCM P0455:00 |
EVAP System Leak Detected - Large Leak: No Sub Type Information |
Sets when the PCM
detects no purge flow, which is attributed to fuel vapor restrictions,
a large fuel vapor leak, or multiple fuel vapor leaks are detected by
the EVAP running loss monitor test with the engine running, but not at
idle. The PCM monitors the complete EVAP control system for no purge
flow, the presence of a large fuel vapor leak, or multiple small fuel
vapor leaks.
Check for audible vacuum noise or significant fuel odor in the engine
compartment or near the EVAP
canister and fuel tank. Verify the capless fuel tank filler pipe is
sealed correctly. Install and remove the supplemental fueling adapter
five times in the capless fuel tank filler pipe to clear debris on the
seal. Refer to the Owner's's Literature for the location of the
supplemental fueling adapter in the vehicle.
|
| PCM P0456:00 |
EVAP System Leak Detected (very small leak): No Sub Type Information |
Sets when the PCM detects a very small fuel vapor leak by the engine
off natural vacuum leak check monitor. Refer to the EVAP Leak Check
Monitor, Engine Off Natural Vacuum Leak Check Monitor description for
additional information.
Check for a
missing fuel filler cap or the integrity of the cap (if equipped).
Verify the capless fuel tank filler pipe is sealed correctly (if
equipped). Install and remove the supplemental fueling adapter five
times in the capless fuel tank filler pipe to clear debris on the seal.
Refer to the Owner's's Literature for the location of the supplemental
fueling adapter in the vehicle. Check for loose or damaged vapor hoses.
Visually inspect the EVAP canister inlet port, EVAP canister vent valve
filter, and EVAP canister vent hose assembly for contamination or
debris.
|
| PCM P0457:00 |
EVAP System Leak Detected (fuel cap loose/off): No Sub Type Information |
Sets when the PCM
detects a gross leak while the refueling flag is set and a loose fuel
filler cap (if equipped) or an incorrectly sealed capless fuel tank
filler pipe (if equipped) is suspected. On most vehicles, a message on
the IPC displays to instruct the driver to check the fuel cap or capless fuel tank filler pipe (if equipped).
The PCM
continuously monitors the fuel level and retains the last updated
value prior to the ignition being placed in the OFF mode. After the
ignition is placed in the ON mode, a new fuel level is taken and
compared to the level recorded at ignition OFF. If the fuel level has
increased, a flag is set in the PCM indicating the vehicle was refueled.
Check for a
missing fuel filler cap or the integrity of the cap (if equipped).
Verify the capless fuel tank filler pipe is sealed correctly (if
equipped). Install and remove the supplemental fueling adapter five
times in the capless fuel tank filler pipe to clear debris on the seal.
Refer to the Owner's's Literature for the location of the supplemental
fueling adapter in the vehicle. If OK, clear the continuous memory
Diagnostic Trouble Codes (DTCs) and test the system for correct
operation.
|
| PCM P0496:00 |
EVAP System High Purge Flow: No Sub Type Information |
Sets when the PCM detects the EVAP running loss monitor detects
excessive fuel tank vacuum with the engine running, but not at idle.
Visually inspect the EVAP canister inlet port, EVAP canister vent valve
filter, and EVAP canister vent hose assembly for contamination or
debris.
Check the EVAP purge valve for vacuum leak.
|
| PCM P04EA:00 |
EVAP System Small Leak Detected - Fuel Tank Side: No Sub Type Information |
Sets when the PCM
detects a fuel vapor leak from an opening as small as 1.016 mm (0.040
in) between the capless fuel filler pipe and the fuel tank isolation
valve.
|
| PCM P04EB:00 |
EVAP System Small Leak Detected - Fresh Air Side: No Sub Type Information |
Sets when the PCM detects a fuel vapor leak from an opening as small as
1.016 mm (0.040 in) between the EVAP leak detection control module and
the fuel tank isolation valve.
|
| PCM P04ED:00 |
EVAP System Large Leak Detected - Fresh Air Side: No Sub Type Information |
Sets when the PCM
detects no purge flow, which is attributed to fuel vapor restrictions,
a large fuel vapor leak, or multiple fuel vapor leaks are detected by
the EVAP monitor. The EVAP
system is monitored for no purge flow, the presence of a large fuel
vapor leak, or multiple small fuel vapor leaks between the EVAP leak
detection control module and the fuel tank isolation valve.
Check for audible vacuum noise or significant fuel odor in the engine
compartment or near the EVAP canister.
|
| PCM P04EE:00 |
EVAP System Very Small Leak Detected - Fuel Tank Side: No Sub Type Information |
Sets when the PCM
detects a fuel vapor leak from an opening as small as 0.508 mm (0.020
inch) is detected between the capless fuel filler pipe and the fuel tank
isolation valve.
|
| PCM P04EF:00 |
EVAP System Very Small Leak Detected - Fresh Air Side: No Sub Type Information |
Sets when the PCM detects a fuel vapor leak from an opening as small as
0.508 mm (0.020 inch) is detected between the EVAP leak detection
control module and the fuel tank isolation valve.
|
| PCM P04F0:00 |
EVAP System High Load Purge Line 'A' Performance: No Sub Type Information |
Sets when the PCM
detects the fuel tank pressure exceeds a calibrated amount within a
specified amount of time during the test (single path check valve), or
when the fuel tank vacuum is less than a calibrated amount within a
specified amount of time or when the fuel tank pressure exceeds a
calibrated amount within a specified amount of time during the test
(dual path check valve). The EVAP check valve test is performed during
minimal boost conditions, once per drive cycle, when entry conditions
are met.
|
| PCM P144A:00 |
EVAP System Purge Vapor Line Restricted/Blocked: No Sub Type Information |
Sets when the PCM
detects the intrusive test confirms a restriction and the counter is
incremented and the counter reaches a calibrated number of completions.
The PCM monitors the EVAP
system for a restricted fuel vapor tube between the fuel tank pressure
sensor and the fuel tank. During the initial phase of the EVAP monitor,
the PCM closes the canister vent and a vacuum develops in the fuel
vapor tubes and lines and in the fuel tank. The PCM
monitors the fuel tank pressure sensor to determine the amount of
vacuum and how quickly the vacuum increases. The rate at which the
vacuum increases is compared to an expected value. If the vacuum
increases quicker than expected, a restricted fuel vapor tube is
suspected and an intrusive test is carried out in the final phase of the
EVAP monitor.
Check the fuel vapor tube for a restriction between the FTP sensor and
the fuel tank.
|
| PCM P144B:00 |
EVAP System Secondary Purge Vapor Line Restricted/Blocked: No Sub Type Information |
Sets when the PCM detects the EVAP vent tube to the EVAP leak detection
control module is restricted.
Check for restrictions in the EVAP vent tube between the EVAP leak
detection control module and the fresh air inlet. Inspect the connectors
for signs of damage or corrosion.
|
| PCM P144C:00 |
EVAP System Purge Flow Performance During Boost: No Sub Type Information |
Sets when the PCM
detects the fuel tank pressure exceeds a calibrated amount within a
specified amount of time during the test (single path check valve), or
when the fuel tank vacuum is less than a calibrated amount within a
specified amount of time or when the fuel tank pressure exceeds a
calibrated amount within a specified amount of time during the test
(dual path check valve). The EVAP check valve test is carried out during
minimal boost conditions, once per drive cycle, when entry conditions
are met.
|
| PCM P1450:00 |
Unable to Bleed Up Fuel Tank Vacuum: No Sub Type Information |
Sets when the PCM detects the EVAP running loss monitor detects
excessive fuel tank vacuum with the engine running, but not at idle.
Visually inspect the EVAP canister inlet port, EVAP canister vent valve
filter, and EVAP canister vent hose assembly for contamination or
debris.
Check EVAP purge valve for vacuum leak.
|
| PCM P2401:00 |
EVAP System Leak Detection Pump Control Circuit Low: No Sub Type Information |
Sets when the PCM detects a concern with the EVAP leak detection control module vacuum pump circuits.
|
| PCM P2402:00 |
EVAP System Leak Detection Pump Control Circuit High: No Sub Type Information |
Sets when the PCM detects a concern is detected with the EVAP leak detection control module vacuum pump circuits.
|
| PCM P2418:00 |
EVAP System Switching Valve 'A' Control Circuit/Open: No Sub Type Information |
Sets when the PCM detects the signal moves outside the minimum or
maximum limit for the commanded state of the EVAP vapor blocking valve.
|
| PCM P2450:00 |
EVAP System Switching Valve 'A' Perfomance/Stuck Open: No Sub Type Information |
Sets when the PCM detects the rate of vacuum loss is greater than a
calibrated threshold.
The PCM commands the EVAP
vapor blocking valve closed while vacuum is present in the fuel tank.
If the valve does not close, the vacuum in the tank is quickly lost.
Retrieve all continuous memory and on-demand self-test Diagnostic
Trouble Codes (DTCs) from the PCM . Diagnose any circuit related EVAP
vapor blocking valve Diagnostic Trouble Codes (DTCs) before diagnosing
this performance DTC .
Visually inspect the EVAP canister inlet port, EVAP canister vent valve
filter, fresh air hose and canister vent hose assembly for
restrictions, contamination or debris.
|
| PCM P2451:00 |
EVAP System Switching Valve 'A' Stuck Closed: No Sub Type Information |
Sets when the PCM detects the rate of loss is less than a calibrated
threshold.
The PCM
commands the fuel tank isolation valve open while a vacuum is present
in the fuel tank. If the fuel tank isolation valve does not open, the
vacuum in the tank remains.
Retrieve all continuous memory and on-demand self-test Diagnostic
Trouble Codes (DTCs) from the PCM . Diagnose and repair circuit DTC
P2418 or any fuel tank pressure (FTP) sensor concerns before diagnosing
this performance DTC .
|
| PCM P24B9:00 |
EVAP System Leak Detection Pump Pressure Sensor Circuit Range/Performance: No Sub Type Information |
Sets when the PCM detects the EVAP leak detection control module pressure sensor signal is out of range.
|
| PCM P24BA:00 |
EVAP System Leak Detection Pump Pressure Sensor Circuit Low: No Sub Type Information |
Sets when the PCM detects the EVAP leak detection control module
pressure sensor signal is less than a minimum allowable calibrated
parameter.
|
| PCM P24BB:00 |
EVAP System Leak Detection Pump Pressure Sensor Circuit High: No Sub Type Information |
Sets when the PCM detects the EVAP leak detection control module
pressure sensor signal is greater than a maximum allowable calibrated
parameter.
|
| PCM P24BC:00 |
EVAP System Leak Detection Pump Pressure Sensor Circuit Intermittent: No Sub Type Information |
Sets when the PCM detects an intermittent concern with the EVAP leak detection control module pressure sensor circuits.
|
| PCM P24BE:00 |
EVAP System Leak Detection Pump Switching Valve Control Circuit Low: No Sub Type Information |
Sets when the PCM detects a concern with the EVAP leak detection control module switching valve circuits.
|
| PCM P24BF:00 |
EVAP System Leak Detection Pump Switching Valve Control Circuit High: No Sub Type Information |
Sets when the PCM detects a concern with the EVAP leak detection control module switching valve circuits.
|
| PCM P24C0:00 |
EVAP System Leak Detection Pump Switching Valve Stuck On: No Sub Type Information |
Sets when the PCM detects the EVAP leak detection control module switching valve is stuck closed.
|
| PCM P24C1:00 |
EVAP System Leak Detection Pump Switching Valve Performance/Stuck Off: No Sub Type Information |
Sets when the PCM detects the EVAP leak detection control module switching valve is stuck open.
|
| PCM P2DDA:00 |
EVAP System Leak Detection Pump Performance/Stuck Off: No Sub Type Information |
Sets when a concern is detected with the EVAP leak detection control module vacuum pump circuits.
|
| PCM P2DDB:00 |
EVAP System Leak Detection Pump Stuck On: No Sub Type Information |
Sets when a concern is detected with the EVAP leak detection control module vacuum pump circuits.
|
| PCM P260F:00 |
EVAP System Monitoring Processor Performance: No Sub Type Information |
Sets when the PCM detects a concern internal to the PCM
. The microprocessor that controls the engine off natural vacuum leak
check monitor is separate from the main processor within the PCM .
Verify the PCM is at the latest calibration level. Reprogram if necessary.
|
PINPOINT TEST HX: EVAPORATIVE EMISSION (EVAP) SYSTEM AND MONITOR.jpg){kind=icon}
PINPOINT TEST HX: EVAPORATIVE EMISSION (EVAP) SYSTEM AND MONITOR
.jpg)
Introduction
Introduction
.jpg)
WARNING:
Before working on or disconnecting any of the fuel
tubes or fuel system components, relieve the fuel system pressure to
prevent accidental spraying of fuel. Fuel in the fuel system remains
under high pressure, even when the engine is not running. Failure to
follow this instruction may result in serious personal injury.
General Procedures - Evaporative Emission System Leak Test
