Ford Escape: Fuel Charging and Controls - Turbocharger - 2.0L EcoBoost (177kW/240PS) – MI4 / Description and Operation - Turbocharger - Component Location

2.0L EcoBoost


Item Description
1 Turbocharger
2 Turbocharger oil supply tube
3 Turbocharger coolant supply tube
4 Turbocharger oil return tube
5 Turbocharger coolant return tube

    Fuel Charging and Controls - Turbocharger - 2.0L EcoBoost (177kW/240PS) – MI4

    ..

    Description and Operation - Turbocharger - System Operation and Component Description

    System Operation Turbocharger And Charge Air Cooler (CAC) Systems A turbocharger is an exhaust gas driven device used to increase the power output of an engine by the turbocharger compressor increasing the pressure of the air entering the engine...
