Ford Escape: Transmission Cooling - Automatic Transmission – HF45 / Removal and Installation - Transmission Fluid Cooler

Removal

  1. Remove the A/C condenser.
    Refer to: Transmission Fluid Cooler (307-02A Transmission Cooling - 8-Speed Automatic Transmission – 8F35/8F40, Removal and Installation).
  1. Release the clips and remove the transmission fluid cooler from the radiator.

Installation

  1. Install the transmission fluid cooler to the radiator and engage the clips.
  1. Install the A/C condenser.
    Refer to: Transmission Fluid Cooler (307-02A Transmission Cooling - 8-Speed Automatic Transmission – 8F35/8F40, Removal and Installation).
