Ford Escape: Automatic Transmission - Automatic Transmission – HF45 / Removal and Installation - Transmission Case Cover
Materials
Name |
Specification |
Motorcraft® Ultra Silicone Sealant TA-29 |
WSS-M4G323-A8
|
Removal
-
Remove the transmission.
Refer to: Transmission (307-01B Automatic Transmission - Automatic Transmission – HF45, Removal and Installation).
-
NOTE:
Mark the location of the studbolts for assembly.
NOTE:
The transmission case cover bolts are low profile
external torx plus® design. Use a 14EPL socket to remove and install the
bolts.
Remove the bolts, studbolts and the transmission case end cover assembly.
Installation
-
NOTICE:
Do not use metal scrapers, wire brushes, power
abrasive discs, or other abrasive means to clean sealing surfaces. These
tools cause scratches and gouges which make leak paths.
Make sure that the mating faces are clean and free of foreign material.
Refer to: RTV Sealing Surface Cleaning and Preparation (303-00 Engine System - General Information, General Procedures).
-
NOTICE:
Do not use metal scrapers, wire brushes, power
abrasive discs, or other abrasive means to clean sealing surfaces. These
tools cause scratches and gouges which make leak paths.
Make sure that the mating faces are clean and free of
foreign material. Apply 276 kPa (40 psi) of air pressure through oil
passages to remove any debris.
Refer to: RTV Sealing Surface Cleaning and Preparation (303-00 Engine System - General Information, General Procedures).
-
Verify the case cover seal is installed.
-
Apply silicone to the transmission case assembly.
Material: Motorcraft® Ultra Silicone Sealant
/ TA-29
(WSS-M4G323-A8)
-
NOTE:
Make sure that the components are installed to the position noted before removal.
Install the transmission case end cover assembly, bolts and studbolts.
Torque:
18 lb.ft (25 Nm)
-
Install the transmission.
Refer to: Transmission (307-01B Automatic Transmission - Automatic Transmission – HF45, Removal and Installation).
