Ford Escape: Exterior Lighting / Removal and Installation - Trailer Module (TRM)
Removal
NOTE:
Removal steps in this procedure may contain installation details.
-
NOTE:
This step is only necessary if the TRM (trailer module) is being replaced.
Using a diagnostic scan tool, begin the PMI process for the TRM following the on-screen instructions.
Refer to: Module Configuration - System Operation and Component
Description (418-01 Module Configuration, Description and Operation).
-
Remove the LH loadspace trim panel.
Refer to: Loadspace Trim Panel (501-05 Interior Trim and Ornamentation, Removal and Installation).
-
Remove the trailer module.
-
Disconnect the trailer module electrical connectors.
-
Remove the trailer module bolts.
Torque:
25 lb.in (2.8 Nm)
Installation
-
To install, reverse the removal procedure.
-
NOTE:
Carry out this step only if the TRM (trailer module) is being replaced.
Using a diagnostic scan tool, complete the PMI process for the TRM following the on-screen instructions.
Refer to: Module Configuration - System Operation and Component
Description (418-01 Module Configuration, Description and Operation).
Removal
NOTE:
Removal steps in this procedure may contain installation details.
Disconnect the stoplamp switch electrical connector.
NOTICE:
Do not press, pull or otherwise move the brake pedal
while installing the stoplamp switch and cruise control deactivation
switch...
Other information:
Materials
Name
Specification
Motorcraft® Metal Brake Parts CleanerPM-4-A, PM-4-B, APM-4-C
-
Removal
NOTE:
Removal steps in this procedure may contain installation details.
Remove the wheel and tire.
Refer to: Wheel and Tire (204-04A Wheels and Tires, Removal and Installation).
Disconnect the electrical connector.
..
System Operation
System Diagram - Exterior, Power
Item
Description
1
DDM
2
PDM
3
Motors
4
LH exterior mirror
5
Exterior mirror control switch
6
LH front door window control switch
7
Motors
8
RH exterior mirror
Network Message Chart
Module Network Input..
