Ford Escape: Front Suspension / Removal and Installation - Front Stabilizer Bar Link
Removal
NOTICE:
Suspension fasteners are critical parts that affect the
performance of vital components and systems. Failure of these fasteners
may result in major service expense. Use the same or equivalent parts if
replacement is necessary. Do not use a replacement part of lesser
quality or substitute design. Tighten fasteners as specified.
NOTE:
Removal steps in this procedure may contain installation details.
-
Remove the wheel and tire.
Refer to: Wheel and Tire (204-04A Wheels and Tires, Removal and Installation).
-
NOTICE:
Do not use power tools to remove the stabilizer bar
link nut. Damage to the stabilizer bar link ball joint or boot may
occur.
NOTE:
The stabilizer bar links are designed with low friction ball joints that have a low breakaway torque.
NOTE:
Use the TORX PLUS® holding feature to prevent the
ball stud from turning while removing or installing the lower arm
outboard nut. Torx® and TORX PLUS® is a reg. tm of Acument Intellectual
Properties, LLC.
-
Remove and discard the front stabilizer bar link upper nut.
Torque:
81 lb.ft (110 Nm)
-
Remove and discard the front stabilizer bar link lower nut.
Torque:
85 lb.ft (115 Nm)
-
Remove the front stabilizer bar link.
Installation
-
To install, reverse the removal procedure.
