Ford Escape: Engine / Removal and Installation - Flywheel

Removal

  1. Remove the transmission.
    Refer to: Transmission (307-01B Automatic Transmission - Automatic Transmission – HF45, Removal and Installation).
  1. Remove the bolts and the damper. Discard the bolts.
    • Remove the bolts and the flywheel.
    • Discard the bolts.

Installation

  1. NOTE: Use a universal pulley holder (such as an OTC 4754, or equivalent).

    • Install the flywheel and the new bolts. Using a universal pulley holder, tighten the new crankshaft pulley bolts in sequence shown.
      Torque:
        Stage 1:  37 lb.ft (50 Nm)
        Stage 2:  59 lb.ft (80 Nm)
        Stage 3:  83 lb.ft (112 Nm)
    • Remove the universal pulley holder.
  1. Using a universal pulley holder, tighten 2 turns at a time in sequence shown.
    Torque: 21 lb.ft (29 Nm)
  1. Install the engine.
    Refer to: Engine (303-01C Engine, Removal).
