Ford Escape 2020-2024 Service Manual / Electrical / Climate Control System / Supplemental Climate Control / Removal and Installation - Cabin Heater Coolant Temperature Sensor

Ford Escape: Supplemental Climate Control / Removal and Installation - Cabin Heater Coolant Temperature Sensor

Special Tool(s) / General Equipment

Hose Clamp(s)

Removal

NOTE: Removal steps in this procedure may contain installation details.

Remove the RH fender splash shield.
Refer to: Fender Splash Shield (501-02 Front End Body Panels, Removal and Installation).

1. Disconnect the electrical connector.
1. Remove the locking clip and remove the cabin heater coolant temperature sensor.
  Use the General Equipment: Hose Clamp(s)

Installation

To install, reverse the removal procedure.

Fill and bleed the cooling system. Refer to the appropriate procedure in Group 303.
