Ford Escape: Engine Cooling / Removal and Installation - Block Heater
Removal
NOTE:
Removal steps in this procedure may contain installation details.
-
Drain the cooling system.
Refer to: Engine Cooling System Draining, Vacuum Filling and Bleeding (303-03C Engine Cooling, General Procedures).
-
Remove the catalytic converter.
Refer to: Catalytic Converter (309-00C Exhaust System, Removal and Installation).
-
NOTE:
Make sure the block heater wiring is routed and secured away from rotating or hot components.
Disconnect the block heater electrical connector.
-
Remove the block heater.
Torque:
41 lb.ft (55 Nm)
Installation
-
To install, reverse the removal procedure.
-
Fill and bleed the cooling system.
Refer to: Engine Cooling System Draining, Vacuum Filling and Bleeding (303-03C Engine Cooling, General Procedures).
