Ford Escape: Intake Air Distribution and Filtering / Removal and Installation - Air Cleaner Intake Pipe

Removal

NOTE: Removal steps in this procedure may contain installation details.

  1. Remove the following items:
    1. Dislodge and position aside the air cleaner intake pipe.
    2. Remove the clips.
    3. Dislodge the air intake pipe and remove it from location.

Installation

  1. To install, reverse the removal procedure.

    Removal and Installation - Air Cleaner Outlet Pipe
