Ford Escape 2020-2024 Service Manual / Powertrain / Automatic Transmission / Automatic Transmission - Automatic Transmission – HF45 / Description and Operation - Transmission Description - Hybrid Electric Vehicle (HEV) - Component Location
Ford Escape: Automatic Transmission - Automatic Transmission – HF45 / Description and Operation - Transmission Description - Hybrid Electric Vehicle (HEV) - Component Location
HF45 Transmission
| Item | Part Number | Description |
|---|---|---|
| 1 | 70487048 | Input shaft oil seal |
| 2 | 11771177 | Right Hand (RH) halfshaft seal |
| 3 | ---- | Damper housing/cover assembly to transmission case bolts (27 required) |
| 4 | 79757975 | Damper housing |
| 5 | 7F4097F409 | Transmission oil sump baffel |
| 6 | 7D2887D288 | Oil collector plate |
| 7 | 7D2887D288 | Oil collector plate |
| 8 | W716607W716607 | Oil collector plate bolt (2 required) |
| 9 | W716607W716607 | Oil collector plate bolt (1 required) |
| 10 | 7F1197F119 | Differential preload shim |
| 11 | 45274527 | Differential bearing cup (damper housing side) |
| 12 | 7F4657F465 | Differential carrier |
| 13 | 42224222 | Differential bearing cup (transmission case side) |
| 14 | 7H3677H367 | Transfer shaft preload shim |
| 15 | 7J4917J491 | Transfer shaft bearing cup (damper housing side) |
| 16 | 7H4717H471 | Transfer gear |
| 17 | 7J4917J491 | Transfer shaft bearing cup (transmission case side) |
| 18 | 7C0987C098 | Traction motor drive gear |
| 19 | W500311W500311 | INDCT hybrid transmission bolts (2 required) |
| 20 | 14G36214G362 | INDCT hybrid transmission |
| 21 | 7B3627B362 | Dowl pin |
| 22 | 7G1017G101 | Park pawl abutment |
| 23 | 7A4417A441 | Park pawl |
| 24 | 7D0717D071 | Park pawl shaft |
| 25 | W500214W500214 | Park lock actuator guide bolts (2 required) |
| 26 | 7D0707D070 | Park pawl spring |
| 27 | 7G2767G276 | Wiring bulkhead |
| 28 | W500214W500214 | Wiring bulkhead bolts (5 required) |
| 29 | 7R2137R213 | Pump and filter assembly |
| 30 | W500305W500305 | Pump and filter assembly bolts (3 required) |
| 31 | 7J3227J322 | Final drive input gear |
| 32 | W716607W716607 | Transmission oil sump baffel bolts (2) |
| 33 | 7L0277L027 | Magnet |
| 34 | 70057005 | Transmission case assembly |
| 35 | 11771177 | Left Hand (LH) halfshaft seal |
| 36 | 7H3757H375 | Ring gear assembly |
| 37 | 7J4657J465 | Traction motor resolver |
| 38 | 7J4817J481 | Transmission vent plate |
| 39 | 7H2997H299 | Traction motor |
| 40 | W715146W715146 | Traction motor bolts (3 required) |
| 41 | 7P0067P006 | Traction motor rotor assembly |
| 42 | 7J4957J495 | Generator/starter |
| 43 | W706284W706284 | Generator/starter bolts (3 required) |
| 44 | 72117211 | Transmission case end cover assembly |
| 45 | ---- | Transmission case end cover assembly bolts (24 required) |
| 46 | 7P0057P005 | Generator/starter rotor |
| 47 | W505575W505575 | Generator/starter resolver bolts (3 required) |
| 48 | 7A1307A130 | Planetary carrier support |
| 49 | 7J4657J465 | Generator/starter resolver |
| 50 | W703645W703645 | Planetary carrier support bolts (4 required) |
| 51 | W500215W500215 | Park lock actuator assembly (3 required) |
| 52 | 7P2367P236 | Park lock actuator assembly |
| 53 | 7H0747H074 | Pump drive gear |
| 54 | 7D4107D410 | Park pawl actuator rod |
| 55 | 7A3987A398 | Planetary carrier |
| 56 | 7A3487A348 | Sun gear |
| 57 | 7D2347D234 | Sun gear thrust bearing |
| 58 | 7B0127B012 | ISC |
| 59 | W718675W718675 | ISC bolts (11 required) |
| 60 | W714629W714629 | ISC studbolts (2 required) |
| 61 | 7P2347P234 | ISC side cover |
| 62 | W720550W720550-S442-S442 | ISC side cover bolts (6 required) (Use with ISC part number suffix -BE and prior) |
| 62 | W720968W720968-S442-S442 | ISC side cover bolts (6 required) (Use with ISC part number suffix -BF and later) |
| 63 | W500211W500211 | High voltage terminal bolts (5 required) |
| 64 | 7P1027P102 | High voltage terminals |
| 65 | W500211W500211 | High voltage terminal bolts (3 required) |
| 66 | 7P1027P102 | High voltage terminals |
.jpg)
| Item | Part Number | Description |
|---|---|---|
| 1 | 7H2997H299 | Traction motor |
| 2 | 7J4957J495 | Generator/starter |
| 3 | 7P1027P102 | High voltage terminals |
| 4 | 7A3987A398 | Planetary carrier |
| 5 | 7P2367P236 | Park rod actuator |
| 6 | 7H1417H141 | Transmission fluid temperature (TFT) sensor |
| 7 | 7R2137R213 | Pump and filter assembly |
| 8 | 7F4657F465 | Differential carrier |
ISC (Inverter System Controller)
.jpg)
The ISC (inverter system controller) is also referred to as the SOBDMC . The ISC is a DC to AC inverter that supplies current to the electric motor and generator/starter and converts AC from the motor and generator/starter to DC to charge the high voltage batteries.
Description and Operation - Transmission Description - Overview
Transmission Overview
The Electronically Controlled Continuously Variable Transmission (eCVT) has the following internal components:
Traction Motor
Generator/Starter
High voltage terminals
Pump and filter assembly
Park lock actuator
TFT sensor
Planetary carrier
Differential carrier
High voltage inductor
Transmission fluid auxiliary pump
..
