Ford Escape: Fuel Charging and Controls - Turbocharger - 1.5L EcoBoost (132kW/180PS) – I3 (Y1) / Removal and Installation - Turbocharger Oil Supply Tube

Materials

Name Specification
Motorcraft® Metal Brake Parts Cleaner
PM-4-A, PM-4-B, APM-4-C
-


Removal

NOTICE: The turbocharger compressor vanes can be damaged by even the smallest particles. When removing any turbocharger or engine air intake system component, ensure that no debris enters the system. Failure to do so may result in damage to the turbocharger.

NOTICE: Special attention needs to be given to the sealing ports for the oil feed, the oil drain, and the coolant lines, on turbocharged engines. The sealing ports must be totally clean and free from O-ring residue, have no damage to the sealing surface and the lines to ensure that there are no leaks or repeat repairs.

  1. Remove the cowl panel grille.
    Refer to: Cowl Panel Grille (501-02 Front End Body Panels, Removal and Installation).
  1. Remove the air cleaner outlet pipe.
    Refer to: Air Cleaner Outlet Pipe (303-12A Intake Air Distribution and Filtering - 1.5L EcoBoost (132kW/180PS) – I3 (Y1), Removal and Installation).
  1. Remove the bolts, then remove and discard turbocharger oil supply tube. Discard the designated bolt.

Installation

  1. NOTICE: A new turbocharger oil supply tube filter must be used. (Part of the oil supply tube.) Failure to use a new filter will cause turbocharger failure.

    Install the new O-rings if not already installed. Lubricate the O-ring seals with clean engine oil.
    Refer to: Specifications (303-01A Engine - 1.5L EcoBoost (132kW/180PS) – I3 (Y1), Specifications).
  1. NOTE: The oil supply tube must be fully seated prior to fastener tightening.

    • Carefully use a nylon brush to remove the old O-ring residue, use brake cleaner to rinse the O-ring residue out of the turbocharger and engine O-ring bores. Inspect the area for deep scratches and gouges. Install new components if needed.
      Material: Motorcraft® Metal Brake Parts Cleaner / PM-4-A, PM-4-B, APM-4-C
    1. Install and fully seat the turbocharger oil supply tube, install and finger tighten the bolts at this stage.
      Torque:
         1 :   89 lb.in (10 Nm)
         2 :   89 lb.in (10 Nm)
         3 :   22 lb.ft (30 Nm)
  1. Install the air cleaner outlet pipe.
    Refer to: Air Cleaner Outlet Pipe (303-12A Intake Air Distribution and Filtering - 1.5L EcoBoost (132kW/180PS) – I3 (Y1), Removal and Installation).
  1. Install the cowl panel grille.
    Refer to: Cowl Panel Grille (501-02 Front End Body Panels, Removal and Installation).
  1. Check and top off the engine oil as needed.
    Refer to: Specifications (303-01A Engine - 1.5L EcoBoost (132kW/180PS) – I3 (Y1), Specifications).
  1. Start and check for leaks.
