Ford Escape: Wipers and Washers / Removal and Installation - Rear Window Wiper Motor

Removal

NOTE: Removal steps in this procedure may contain installation details.

Remove the rear window wiper pivot arm.
Refer to: Rear Window Wiper Pivot Arm (501-16 Wipers and Washers, Removal and Installation).

Remove the liftgate trim panel.
Refer to: Liftgate Trim Panel (501-05 Interior Trim and Ornamentation, Removal and Installation).

1. Disconnect the rear wiper motor electrical connector and position the harness aside.
1. Remove the rear wiper motor retainers and the rear wiper motor.
  Torque: 97 lb.in (11 Nm)

Installation

To install, reverse the removal procedure.
