Ford Escape: Glass, Frames and Mechanisms / Removal and Installation - Rear Door Glass Top Run

Removal

NOTE: LH (left-hand) shown, RH (right-hand) similar.

NOTE: Removal steps in this procedure may contain installation details.

  1. Remove the rear door window glass.
    Refer to: Rear Door Window Glass (501-11 Glass, Frames and Mechanisms, Removal and Installation).
  1. Remove the fore rear door upper moulding.
    Refer to: Rear Door Upper Moulding (501-08 Exterior Trim and Ornamentation, Removal and Installation).

  1. Remove the rear door glass top run.
    1. Position the rear door glass top run.
    1. Position the rear door glass top run.
    1. Position the rear door glass top run.
    1. Remove the rear door glass top run.

Installation

  1. To install, reverse the removal procedure.
  1. If the door is equipped with one touch up/down, carry out the power door window initialization. Refer to: Power Door Window Initialization - Vehicles With: One-Touch Open and Close Front Windows (501-11 Glass, Frames and Mechanisms, General Procedures).
