Other information:
System Operation
System Diagram
Item
Description
1
GWM
2
RH steering wheel switch
3
PSCM
4
BCM
5
Door/liftgate ajar switches
6
SODR
7
Fuel pump and sender unit
8
IPC
9
APIM
10
Washer fluid level switch
11
Message center display
12
PCM
13
Engine oil pressure sensor..
Removal
NOTICE:
During the removal of components, cap, tape or otherwise
appropriately protect all openings to prevent the ingress of dirt or
other contamination. Remove protective materials prior to installation.
NOTE:
Removal steps in this procedure may contain installation details.
Recover the refrigerant. Refer to the appropriate Recovery procedure in Group 412.
..
