Ford Escape: Glass, Frames and Mechanisms / Removal and Installation - Front Door Window Glass
Special Tool(s) /
General Equipment
Removal
NOTE:
LH (left-hand) side shown, RH (right-hand) side similar.
-
Remove the front door trim panel.
Refer to: Front Door Trim Panel (501-05 Interior Trim and Ornamentation, Removal and Installation).
-
Remove the front door window glass release access covers.
-
Lower the front door window glass to the half down position.
-
Connect the window control switch.
-
Lower the front door window glass to the half down position.
-
Align the front door window glass retaining clips with the access windows.
-
Disconnect the window control switch.
-
Remove the front door upper trim.
-
Remove the pin-type retainer.
-
Remove the pin-type retainer and release the front door upper trim.
-
Release the front door upper trim.
-
Release the front door upper trim.
-
Remove the front door upper trim.
-
Remove the front door inner belt moulding.
-
Remove the front door window glass.
-
Release the front door window glass retaining clips.
Use the General Equipment: Punch
-
NOTE:
For the RH (right-hand) side, rotate 45 degrees counter-clockwise.
Rotate the front door window glass 45 degrees clockwise.
-
Remove the front door window glass.
Installation
-
To install, reverse the removal procedure.
-
If the door is equipped with one touch up/down, carry out the power
door window initialization.
Refer to: Power Door Window Initialization - Vehicles With: One-Touch
Open and Close Front Windows (501-11 Glass, Frames and Mechanisms,
General Procedures).
Removal
NOTE:
LH (left-hand) side shown, RH (right-hand) side similar.
NOTE:
Removal steps in this procedure may contain installation details.
Remove the front door window glass...
Special Tool(s) /
General Equipment
Punch
Removal
WARNING:
The following procedure prescribes critical repair steps
required for correct restraint system operation during a crash...
